A-B 1756-EN2TXT ETHERNET COMMUNICATIONS BRIDGE

A-B 1756-EN2TXT Ethernet Communications Bridge: Key Functions

The ‌A-B 1756-EN2TXT‌ is a robust EtherNet/IP communication module designed for industrial automation systems.
Its primary role is to facilitate seamless data exchange and network integration within ControlLogix architectures, particularly in demanding environments.

1. Core Functions‌

Network Bridging & Data Routing‌:
Acts as a bridge between ControlLogix systems and EtherNet/IP networks, enabling data routing across multiple ControlLogix chassis (up to 4 racks/8 communication hops).
Supports ‌embedded switch technology‌ for efficient network expansion and reduced cabling complexity.

High-Speed Industrial Communication‌:
Delivers ‌256 Logix connections‌ for high-throughput data exchange, ensuring real-time control and monitoring in applications like motion control and distributed I/O.
Uses ‌EtherNet/IP protocol‌ (10/100 Mbps) to streamline integration with Allen-Bradley PLCs, HMIs, and third-party devices.

Environmental Resilience‌:
Designed for ‌extreme conditions‌ (via ControlLogix-XT compatibility), including resistance to vibration, temperature fluctuations, and dust ingress.
Features ‌corrosion-resistant connectors‌ for reliable operation in harsh industrial settings.

Enhanced Security & Diagnostics‌:
Supports secure communication with CIP Security protocols, safeguarding data integrity in critical infrastructure.
Provides embedded diagnostics (e.g., IP traffic monitoring, connection management) for rapid troubleshooting.

2. Technical Specifications‌

Protocol Support‌: EtherNet/IP, TCP/IP
Max Connections‌: 256 Logix connections
Network Topology‌: Linear (RJ45 port) or star (with switches)
Power Consumption‌: 3.7 W (12.6 BTU/hr)
Compatibility‌: ControlLogix-XT, CompactLogix, PLC-5

3. Key Applications‌

Multi-Network Integration‌: Bridges EtherNet/IP with legacy systems (e.g., DeviceNet, ControlNet) for unified data management.
Remote I/O Control‌: Acts as a remote I/O adapter, enabling configuration and monitoring of distributed modules.
Critical Infrastructure‌: Ensures fail-safe communication in power plants, oil refineries, and automotive production lines.
Network Simplification‌: Reduces network layers by consolidating control, safety, and diagnostics on a single EtherNet/IP backbone.

Combining high-speed data exchange with industrial-grade durability, the 1756-EN2TXT optimizes network performance in complex automation workflows.
