ABB 5SHX0660F0002 Silicon Controlled Rectifier (SCR) Module
1. Core Function
Acts as a high-power thyristor (SCR) module for precise switching and control of large electrical currents in industrial and energy systems.
Enables efficient power conversion and regulation in AC/DC applications, such as motor drives and grid infrastructure.
2. Key Features
High voltage/current capacity: Supports up to 1200V breakdown voltage and 1500A saturation current.
Fast switching: Optimized for rapid power control with minimal losses.
Programmable logic: Allows customization of control algorithms for diverse applications.
Robust thermal design: Integrated heat dissipation ensures stability in high-load conditions.
3. Applications
Industrial motor control: Speed regulation for pumps, compressors, and rolling mills.
Power transmission: Used in HVDC systems and FACTS for grid stability.
Heating systems: Controls resistive/inductive heating elements in industrial furnaces.
Welding equipment: Manages current/voltage in arc welding machines.
4. Compatibility
Integrates with ABB’s medium-voltage drives (e.g., ACS 6000) and DCS systems.
Compatible with IGCT-based power stacks (e.g., 5SHY series).
Note: This module is a critical component in ABB’s power electronics portfolio, combining reliability with advanced control capabilities.
