ABB 5SHY35L4512 3BHE014105R0001 5SXE08-0166 Asymmetric IGCT Module
1. Core Function
Functions as an asymmetric Integrated Gate-Commutated Thyristor (IGCT), optimized for high-power switching in unidirectional current applications.
Combines the robustness of thyristors with fast switching capabilities, enabling efficient energy conversion in high-voltage systems.
2. Key Features
High power ratings: Rated for 4500A current and 3500V voltage, suitable for demanding industrial environments.
Low conduction losses: Minimizes energy dissipation during operation.
Asymmetric design: Tailored for applications requiring unidirectional current flow (e.g., rectifiers, DC links).
Rugged packaging (5SXE08-0166): Ensures thermal stability and mechanical durability.
3. Applications
HVDC power transmission: Used in converter stations for efficient DC voltage conversion.
Industrial drives: Controls high-power motors in steel, mining, and cement industries.
Renewable energy inverters: Integrates with solar/wind power systems for grid synchronization.
Static VAR compensators (SVCs): Manages reactive power in electrical grids.
4. Compatibility
Compatible with ABB’s 5SHY/5SHX series power stacks and control units like 3BHE014105R0001.
Often paired with gate driver units (e.g., 5SXE10-0181) for system integration.
Note: This asymmetric IGCT module is critical for high-efficiency power conversion in unidirectional high-voltage applications.
