The ABB 83SR06B-E GJR2395400R1210 Control Board is a high-performance control module integrated into ABB’s HVDC (High Voltage Direct Current) converter valve systems,
designed for precise power regulation and system management in high-voltage transmission applications.
Key Functions:
1. Power Control & Regulation:
Manages voltage and current in HVDC converter valves, ensuring stable power flow between AC and DC grids.
Optimizes switching losses (7.0 J) and conduction losses (3.5 V) for energy efficiency.
2. System Supervision & Protection:
Monitors real-time operational parameters (e.g., 10,000V rated voltage, 6,000A current capacity) to trigger protective actions during faults.
Implements overcurrent/overvoltage protection to safeguard equipment.
3. Communication & Coordination:
Interfaces with Symphony Plus DCS or PLC networks (e.g., ModbusTCP, Profibus) for centralized control.
Coordinates with other converter modules for synchronized operation.
4. Technical Highlights:
High-power handling: Supports 175°C junction temperature and 2kHz switching frequency.
Robust design: IP20 protection, -20°C to +60°C operating range.
5. Applications:
HVDC transmission stations (e.g., intercontinental power grids).
Renewable energy (wind/solar farms with grid integration).
Industrial drives (high-power motor control).
