ABB CI871AK01 3BSE092693R1 PROFINET I/O Interface Module
1. Core Functionality
The CI871AK01 is a PROFINET I/O communication interface designed for ABB’s AC 800M controllers, enabling real-time data exchange between the controller and PROFINET-compatible devices (I/O modules, drives, sensors) in industrial automation systems.
2. Key Features
Dual-Port PROFINET Interface:
10/100 Mbps Ethernet ports with auto-negotiation
Supports PROFINET IO (Conformance Class B) and RT/IRT communication
High Performance:
Cycle times as low as 1ms for real-time control
Supports up to 256 I/O modules per controller
Advanced Diagnostics:
Comprehensive LED indicators for network status
SNMP support for network monitoring
Robust Design:
-40°C to +70°C operating temperature range
DIN rail mounting for industrial environments
3. Technical Specifications
Protocol Support: PROFINET IO Conformance Class B
Network Ports: 2x RJ45 (switch functionality)
Data Rate: 10/100 Mbps, full/half duplex
Max Devices: 256 I/O modules
Cycle Time: Configurable from 1ms
Power Supply: 24V DC via backplane
4. Typical Applications
Factory Automation: Integration with PLCs and distributed I/O systems
Process Control: Connection to field devices in continuous processes
Motion Control: Synchronization of drives and servo systems
Energy Management: Monitoring of power distribution equipment
