The ABB FI830F 3BDH000032R1 PROFIBUS-DPV1 Fieldbus Module is a high-performance industrial communication interface designed for seamless integration into automation systems.
Here’s a structured technical overview:
1. Core Functions
PROFIBUS-DPV1 Protocol Support:
Operates as a DP slave (Class 1) with baud rates up to 12 Mbps, enabling deterministic data exchange for real-time control.
Supports acyclic parameter access (DPV1 extensions) for advanced diagnostics and configuration.
System Integration:
Features galvanic isolation (1500V AC) between fieldbus and backplane to prevent ground loops.
Hot-swappable design allows maintenance without disrupting operational processes.
Diagnostics & Monitoring:
Provides channel-level fault detection (short-circuit, wire breaks) and LED status indicators (RUN/BUS/ERR) for quick troubleshooting.
Stores PROFIBUS communication statistics (error counts, retries) for performance analysis.
2. Key Specifications
Compliance: EN 50170 (PROFIBUS-DP), IEC 61158-2.
Power Supply: 24V DC (18–32V range) with reverse polarity protection.
Environmental: -25°C to +60°C operation (IP-rated enclosure).
Redundancy: Supports redundant controller configurations for high-availability systems.
3. Typical Applications
Process automation (ABB 800xA/Symphony DCS integration).
Manufacturing lines (PLC-to-PLC communication).
Power plant control systems (turbine I/O networks).
