ABB SHX1960L0006 3BHB016120R0002 GVC736BE101 Silicon Controlled Rectifier (SCR) – Functional Overview
1. Core Functions
Power Regulation: Controls high-voltage/high-current AC/DC power flow in industrial systems (e.g., motor drives, rectifiers).
Phase Control: Enables precise switching via gate signals for adjustable output voltage/current.
Overload Protection: Integrated snubber circuits suppress voltage spikes to protect connected equipment.
2. Key Features
High Power Handling: Supports currents up to 2000A and voltages exceeding 6kV.
Fast Switching: Turn-on/turn-off times in microseconds for dynamic control.
Robust Construction: Press-pack design for efficient heat dissipation in harsh environments.
3. Applications
Industrial Drives: Used in ABB ACS800/ACS6000 transducer for motor speed control.
Power Conversion: Key component in HVDC rectifiers and electrolysis systems.
Energy Storage: Manages power flow in battery charging/discharging systems.
4. Technical Specifications
Part Number: 3BHB016120R0002 (variant: SHX1960L0006, GVC736BE101).
Mounting: Bolt-on or press-fit for secure high-power connections.
