GE 0880001-01 FANUC QUICKPANEL QPI-2D100-L2P-F OPERATOR PANEL Functional Overview
1. Core Functions
Human-Machine Interface (HMI):
Serves as an interactive control interface for industrial automation systems, enabling real-time monitoring and operation of equipment such as gas turbines and motor drives through parameter configuration, status visualization, and fault diagnostics.
Provides tactile input methods (physical buttons, touchscreen, or rotary knobs) for rapid command execution, including mode switching, program start/stop, and parameter adjustments.
Multi-Protocol Communication:
Integrates serial (RS-232/485) and Ethernet (10BaseT/100BaseTX) interfaces, supporting protocols like Modbus and DNP3.0 for seamless data exchange with PLCs and DCS systems.
2. Hardware Features
Robust Industrial Design:
Built with shock-resistant and corrosion-resistant materials, suitable for harsh environments such as high vibration, dust, and extreme temperatures (-40°C to 85°C).
Modular terminal blocks simplify integration with GE Fanuc controllers (e.g., QuickPanel+) and expansion modules.
Programmable Logic Capability:
Embeds PLC functionality, supporting IEC-standard programming languages (ladder logic, structured text) for custom control logic and dynamic interface animations.
3. Application Scenarios
Gas Turbine Control Systems:
Deployed in GE Speedtronic systems as the primary interface for turbine speed regulation, fuel valve adjustments, and safety interlocks.
Industrial Automation Lines:
Integrated into CNC machines, servo drives, or conveyor systems to manage processing parameters, motion trajectory monitoring, and multi-axis coordination.
4. Technical Advantages
Multi-Language Support:
Enables dynamic language switching on the interface to accommodate global industrial operations.
Rapid Development Tools:
Offers pre-configured animation libraries and shared database architectures, significantly reducing development time and simplifying maintenance workflows.
This operator panel exemplifies GE Fanuc’s expertise in delivering highly customizable, durable HMI solutions for complex industrial control environments.
