GE DS200SDCIG1ABA Power Supply Board – Mark V Turbine Control System
1. Primary Function
The DS200SDCIG1ABA is a Power Supply Board designed for GE’s Speedtronic™ Mark V turbine control system. It provides regulated DC power to critical control modules, ensuring stable operation of the turbine protection and automation system.
2. Key Roles & Features
A. Power Conversion & Regulation
Converts incoming AC/DC input power (typically 120V AC or 125V DC) into low-voltage DC outputs (e.g., +5V, ±15V, +24V, +48V) for:
Mark V control processors (e.g., <CPU> boards).
I/O modules (analog/digital signal conditioning).
Communication & relay circuits.
Maintains voltage stability under load fluctuations to prevent system faults.
B. Redundancy & Fault Tolerance
Supports N+1 redundancy in critical applications (parallel power supplies for failover).
Overvoltage/overcurrent protection to safeguard downstream electronics.
C. Diagnostic & Monitoring
LED status indicators for power health (input/output voltage, fault conditions).
May integrate with Mark V diagnostics to alert operators of power anomalies.
D. Industrial Reliability
Designed for 24/7 operation in harsh environments (high temps, vibration, EMI).
Filtered outputs to minimize electrical noise in sensitive control circuits.
3. Typical Applications
Primary power distribution for Speedtronic Mark V racks.
Backup power integration in TMR (Triple Modular Redundant) systems.
Turbine safety systems (overspeed protection, emergency shutdowns).
